Product List
  •
    • Impact Wrenches

    • Ingersoll Rand brings over 60 years of experience to impact wrench design and manufacturing. Ingersoll Rand impact tools are renowned world wide as the most reliable and tough tools available. The twin hammer mechanism developed by Ingersoll Rand provides unmatched durability and performance and has been the industry standard for several years.

      Torque figures shown in the catalogue represent torque achieved under test conditions. Due to joint losses (see fig.) the actual torque achieved on a joint will vary. It is therefore recommended that impact wrenches be selected after actual trials wherever possible.

      Technical Specifications:

      Model Sq. Drive (in) Impact Mechanism Handle Free Speed (rpm) Working Torque Range (Nm) Max. Torque (Nm) Net Wt. (kg) Average Air Cons.(cfm*)









      211/WI 3/8 J S 10000 27 -170 203 1.10 2.5
      212/WI 3/8 J P 10000 27 - 203 244 1.30 2.5
      IR2115Ti# 3/8 T P 15000 34 - 312 339 1.1 4.0
      IR2115QTi* 3/8 T P 15000 34 - 312 339 1.1 4.0
      211R2/WI 1/2 J S 10000 27 -170 203 1.10 2.5
      212R2/WI 1/2 J P 10000 27 - 203 244 1.30 2.5
      IR231H 1/2 T P 8000 34 - 407 610 2.60 4.2
      IR2135TiMAX# 1/2 T P 9500 68 - 814 848 1.79 5.0
      IR2135QTiMAX* 1/2 T P 9500 68 - 814 848 1.79 5.0
      IR2141# 3/4 T P 7250 271 - 1220 1627 3.20 9.5
      IR2171XP 1 T P 6000 408 - 1356 1695 5.95 9.5
      IR280 1 T S 6000 204 - 1356 2169 9.98 10.0
      IR290 1 T P 6000 204 - 1356 2169 9.93 10.0
      IR2190Ti 1 T S 6800 204 -1627 2305 6.1 12.0

  •
    • sub category2product

    • This is test description for sub category2product.

  •
    • Oil Pump (Pro-Series Pumps)

    • Specialty Pumps - Oil Packages

      Oil Package Performance Specifications:

      Ratio: 5::1
      Maximum Flow: GPM (LPM) 9 (34.1)
      Max. Working Flow: 6-g.p.m. (22.7-l.p.m.)
      Maximum Rec’d Cycles: 170 per minute LM2305A-31-B
      Displacement per Cycle: 8.3-In3 (136-cm3)
      Air Inlet: (Female) 1/4 - 18 N.P.T.F. - 1
      Fluid Inlet: 1-1/2 - 11-1/2 N.P.T.F. - 1
      Fluid Outlet: 1/2 - 14 N.P.T.F. - 1
      Max. operating pressure: 150-psi (10.3-bar)
      Fluid Pressure Range: 0-750-psi (0-51.7-bar)
      Weight: lbs (kg) 44.7 (20.3)




      Major Components:

      Item: Description:
      Basic 5:1 Oil Pump: LM2305A-31-B
      Digital Meter: 635190-1 (Pint--LP3100-1-B)
      635190-3 (Liter--LP3101-1-B)
      Drum Cover: 94421
      Material Hose: 623501-6
      Fluid Control Handle: 635391-1
      Dolly Assembly: 640058-2



      Accessories:

      Air Line Connection Kit* | Kit No. 66073-1

      Kit includes Piggyback Filter/Regulator with gauge, pipe nipple and a 5-foot section of air hose.

      Service Repair Kits | Kit No. 637226 (Pump Rebuild Kit: Contains necessary soft parts to rebuild entire pump.)

      *Please note pumps are not included with these kits.

  •
    • Screw Driver

    • Ingersoll Rand dominates the industry with the most comprehensive range of pneumatic screwdrivers. Shut-off, slip & positive clutch models are offered in different speeds in straight, pistol grip and right angle configurations.

      The auto shut off range is recommended for applications requiring torque consistency. Shut off tools also minimise component breakage during fastening of fragile plastic & bakelite components. Auto start screwdrivers minimise operator fatigue, allow faster operations and reduce air consumption. Right-angle screwdrivers have been designed for applications with limited access and are more comfortable on high torque applications.

      Technical Specifications:

      *20% of air consumption at full load.
      41 series screwdrivers are also available with finder type bit holders.


      Model Torque Range(Nm) Free Speed (rpm) Overall Length (mm) Body Diameter (mm) Weight (kg) Average Air Cons. (cfm*)
      AUTO SHUT OFF SCREWDRIVERS
      Straight Handle Auto Start




      		mm
      1RPLS1/WI 0.4 - 1.45 2800 - 28 0.50 1.6
      1RPMS1/WI 0.28 - 2.30 1650 223 28 0.50 1.6
      1RPNS1/WI 0.17 - 3.40 1000 223 28 0.50 1.6
      IRPQS1/WI 0.15 - 5.10 500 - 28 0.50 1.6
      41SA17PSQ4/WI 1.70 - 7.00 1700 277 40 1.20 6.0
      41SA10PSQ4/WI 1.70 - 9.00 1000 277 40 1.20 6.0
      Weight





      Lever Start





      QS1L10S1D 0.30 - 4.50 1000 241 44 0.70 3.2
      QS1L02S1D 0.30 - 5.40 250 241 44 0.70 3.2
      LD2206RD5Q4 3.20 - 8.00 200 243 34 0.80 3.9
      LD1202RD5Q4 4.00 -10.00 600 272 36 1.00 5.3







      Pistol Type Auto Start





      QP1P10S1D 0.30 - 4.50 1000 224 30 0.84 3.2
      QP1P05S1D 0.30 - 5.40 500 224 30 0.84 3.2
      41PA16PSQ4/WI 1.70 - 6.80 1600 249 44 1.36 5.6
      41PA8PSQ4/WI 1.70 -11.30 800 249 44 1.36 5.6







      Trigger Start





      QP1S10S1D 0.30 - 4.50 1000 224 30 0.84 3.2
      41PA16TSQ4/WI 1.70 - 6.80 1600 249 44 1.36 5.6
      41PA8TSQ4/WI 1.70 -11.30 800 249 44 1.36 5.6







      Trigger Permit





      1RTMS1/WI 0.28 - 2.30 1650 218 34 0.68 1.6
      1RTNS1/WI 0.17 - 3.40 1000 218 34 0.68 1.6
      1RTQS1/WI 0.17 - 5.10 500 223 34 0.68 1.6







      Right Angle Screwdrivers





      1RLN2S3/WI 0.20 - 5.30 1/4 Hex 700 318 0.8 1.6







      CUSHION CLUTCH SCREWDRIVERS
      Straight Handle Auto Start





      1RPNC1/WI 0.17 - 3.40 1000 223 28 0.48 1.6
      1RPMC1/WI 0.28 - 2.30 1650 223 28 0.48 1.6
      41SC10PSQ4/WI 1.10 - 6.80 1700 277 40 1.36 4.0
      41SC17PSQ4/WI 1.10 - 9.00 1000 277 40 1.36 4.0







      Lever Start





      1RLNCI/WI 1.70 - 3.40 1000 233 28 0.50 1.6







      Pistol Type Trigger Start





      1RAMC1/WI 0.28 - 2.30 1650 218 34 0.68 1.6
      1RANC1/WI 0.17 - 3.40 1000 218 34 0.68 1.6







      Auto Start





      41PC16PSQ4/WI 1.70 - 6.80 1600 249 44 1.36 5.6
      41PC8PSQ4/WI 1.70 - 11.30 800 249 44 1.36 5.6







      Positive Clutch Screwdriver





      7672 - A18/WI 8.5 1800 169 44 1.20 5.6

  •
    • Electric Nut Runners

    • Ingersoll Rand offers a complete range of DC fastening tools in straight, right angle and (a unique) push-to-start configurations.

      Ingersoll Rand DC fastening tools have built in torque transducers. The torque delivered by the tool is dynamically measured by the transducer and through a closed loop micro processor control, the tool is shut off when the desired torque is achieved. Angle control is attained through a resolver interfaced with the closed loop system. Advance strategies such as fastening to yield are achieved through algorithms.

      The new IR QE-IC series fastening systems are the realization of an investment in innovation and technology that promises and delivers an unparalleled level of performance. The new QEIC systems perform dramatically better than existing closed-loop DC platforms in improving productivity, reducing cost of ownership and maintenance, and offering a proven means of tightening critical assemblies.

      TOOL

      Three motor platforms named the QE4, QE6 and QE8 include tools in angle, inline, push-to-start and pistol configurations.

      Productivity

      »  Faster speeds at torque

      »  Improved accuracy with Sine Drive technology

      »  Programmable momentary switch

      »  Modular designs offer optimum flexibility

      Ergonomics

      »  Lightweight design

      »  Compact package

      »  Comfortable grip surfaces and smooth contours

      »  Low-force trigger and rotary reverse switch

      Reliability

      »  Digital Link between tool and controller

      »  One-piece rugged chassis

      »  Improved gear and cable life

      »  Non-contacting switches

      Technical Specifications:

      Model Max Torque (Nm) Recmd. Torque Range (Nm) Free Speed (rpm) Weight (kg) Sq. Drive (in) Bolt Size(mm)
      QE ANGLE





      QE4AT013PA2H04 13 3-10 1200 1.3 1/4 Hex M5-M6
      QE4AT020PA2S06 20 4-16 820 1.3 3/8 M6-M8
      QE4AT027PA4S06 27 5-22 600 1.3 3/8 M8
      QE4AT034PA4S08 34 7-27 470 1.3 1/2 M8
      QE6AT030PA4S08 30 6-24 1230 1.9 1/2 M8
      QE6AT040PA4S08 40 8-32 910 1.9 1/2 M8
      QE6AT055PA5S08 55 11-44 650 1.9 1/2 M10
      QE6AT080PA5S08 80 16-64 440 1.9 1/2 M10
      QE8AT065PA5S08 65 13-52 1200 2.9 1/2 M10
      QE8AT070PA5S08 70 14-56 1100 2.9 1/2 M10
      QE8AT090PA6S08 90 18-72 850 2.9 1/2 M10
      QE8AT115PA6S08 115 23-92 660 2.9 1/2 M12
      QE8AT150PA6S08 150 30-120 510 2.9 1/2 M12-M14
      QE8AT225PA7S12 225 45-180 310 4.1 3/4 M16
      QE8AT400FA8S12 400 80-320 170 6.0 3/4 M18







      QE INLINE





      QE4ST010B41Q04 10 2-8 1820 1.2 1/4 Hex M4-M5
      QE4ST015B41Q04 15 3-11 1220 1.2 1/4 Hex M5-M6
      QE4ST020B41S06 20 4-16 900 1.2 3/8 M6-M8
      QE4ST025B41S06 25 5-20 710 1.2 3/8 M6-M8
      QE6ST020F61S06 20 4-16 1840 2.1 3/8 M6-M8
      QE6ST028F61S06 28 6-22 1360 2.1 3/8 M8
      QE6ST033F61S08 33 7-26 1130 2.1 1/2 M8
      QE6ST050F61S08 50 10-40 760 2.1 1/2 M10
      QE8ST055F61S08 55 11 -44 1470 3.0 1/2 M10
      QE8ST070F61S08 70 14-56 1470 3.0 1/2 M10
      QE8ST090F61S08 90 18-72 1160 3.0 1/2 M10
      QE8ST150F61S08 150 30-120 500 3.4 1/2 M12-M14
      QE8ST230F62S12 230 45-185 340 5.5 3/4 M16







      QE PUSH TO START



      QE4TS010R11Q04 10 2-8 1820 1.2 1/4 Hex M4-M5
      QE4TS015R11S06 15 3-12 1220 1.2 3/8 M5-M6
      QE4TS020R11S06 20 4-16 900 1.2 3/8 M6-M8
      QE4TS025R11S06 25 5-20 710 1.2 3/8 M6-M8





      QE PISTOL GRIP



      QE4PT010P10Q04 10 2-8 1820 1.2 1/4 Hex M4-M5
      QE4PT015P10S04 15 3-12 1220 1.2 3/8 M5-M6
      QE4PT020P10S06 20 4-16 900 1.2 3/8 M6-M8
      QE4PT025P10S06 25 5-20 710 1.2 3/8 M6-M8

  •
    • Angle Nutrunners

    • There’s much more to an assembly application than merely putting wrench to bolt. It’s an intricate matter of linking tool users and fasteners to deliver an

      uncompromised combination of accuracy, durability, speed, and ergonomics.

      The solution: Ingersoll Rand precision air nutrunners.

      Our newly designed precision air nutrunners are compact, lightweight, quiet, and durable enough for the toughest high-volume applications, yet still

      deliver the speed and accuracy you need. The QA4, QA6, and QA8 Series tools are easy to maintain — which means less downtime — and are fully

      configurable in straight or angle configurations, shut-off or stall, with fixed or floating spindles, and in a variety of drive sizes up to 225 Nm.

      Technical Specifications of  Angle Shutoff Nutrunners:
      		@90 psi / 620 kPa





      		Sq. Drive Torque Range rpm Weight Length

      		Air Consumption
      Model in Nm rpm kg mm mm mm (cfm)
      QA4 Series Shut-off —







      QA4AALS011NP25S06W 3/8" 5 – 11 1025 1.44 342 33 13 27
      QA4AALS015NP25S06W 3/8" 7 – 15 800 1.44 342 33 13 27
      QA4AALS020NP25S06W 3/8" 10 – 20 625 1.44 342 33 13 27
      QA4AALS020NP28S06W 3/8" 10 – 20 625 1.52 363 35 14 27
      QA4AALS030NP28S06W 3/8" 15 – 30 425 1.52 363 35 14 27
      QA4AALS040NP35S06W 3/8" 20 – 40 325 1.81 395 44 18 27
      QA4AALS040NP35S08W 1/2" 20 – 40 325 1.81 395 44 18 27
      QA4AALS055NP35S08W 1/2" 25 – 55 200 2.04 418 44 18 27
      QA6 Series Shut-off —
      QA6AALS030NP35S06W 3/8" 15 – 30 580 2.29 429 44 18 36
      QA6AALS040NP35S06W 3/8" 20 – 40 430 2.29 429 44 18 36
      QA6AALS040NP35S08W 1/2" 20 – 40 430 2.30 429 44 18 36
      QA6AALS055NP35S08W 1/2" 25 – 55 320 2.30 429 44 18 36
      QA6AALS070NP43S08W 1/2" 35 – 70 225 2.30 422 45 22 36
      QA6AALS090NP43S08W 1/2" 45 – 90 185 2.30 422 45 22 36
      QA8 Series Shut-off —
      QA8AALS040NP35S06W 3/8" 20 – 40 570 2.44 453 44 18 41
      QA8AALS040NP35S08W 1/2" 20 – 40 570 2.45 453 44 18 41
      QA8AALS055NP35S08W 1/2" 25 – 55 425 2.45 453 44 18 41
      QA8AALS070NP43S08W 1/2" 35 – 70 320 2.45 445 45 22 41
      QA8AALS090NP43S08W 1/2" 45 – 90 255 2.45 445 45 22 41
      QA8AALS115NP48S08W 1/2" 70 – 115 200 2.79 452 50 25 41
      QA8AALS150NP48S08W 1/2" 75 – 150 145 3.12 489 50 25 41
      QA8AALS200NF56S12W 3/4" 100 – 200 110 4.02 508 53 30 41
      QA8AALS225NF56S12W 3/4" 125 – 225 90 4.02 508 53 30 41




      Technical Specifications of       Angle Stall Air Nutrunners
      		@90 psi / 620 kPa @ 77 psi / 530 kPa





      		Sq. Drive Torque Range rpm Torque Range Weight Length

      		Air Consumption
      Model in Nm rpm Nm kg mm mm mm (cfm)
      Model QA4 Series Shut —
      QA4AALD011NP25S06W 3/8" 11 1025 10 1.12 283 33 13 27
      QA4AALD015NP25S06W 3/8" 15 800 13 1.12 283 33 13 27
      QA4AALD020NP25S06W 3/8" 20 625 17 1.12 283 33 13 27
      QA4AALD030NP28S06W 3/8" 30 425 26 1.20 283 35 14 27
      QA4AALD040NP35S06W 3/8" 40 325 34 1.48 336 44 18 27
      QA4AALD055NP35S08W 1/2" 55 200 46 1.76 359 44 18 27
      QA6 Series Stall —
      QA6AALD030NP35S06W 3/8" 30 580 27 2.11 429 44 18 36
      QA6AALD040NP35S06W 3/8" 40 430 35 2.11 429 44 18 36
      QA6AALD040NP35S08W 1/2" 40 430 35 2.12 429 44 18 36
      QA6AALD055NP35S08W 1/2" 55 320 49 2.12 429 44 18 36
      QA6AALD070NP43S08W 1/2" 70 225 62 2.12 422 45 22 36
      QA6AALD090NP43S08W 1/2" 90 185 80 2.12 422 45 22 36
      QA8 Series Stall —
      QA8AALD040NP35S06W 3/8" 40 570 35 2.26 453 43.5 18 41
      QA8AALD040NP35S08W 1/2" 40 570 35 2.27 453 43.5 18 41
      QA8AALD055NP35S08W 1/2" 55 425 49 2.27 453 43.5 18 41
      QA8AALD070NP43S08W 1/2" 70 320 62 2.27 445 44.7 22 41
      QA8AALD090NP43S08W 1/2" 90 255 80 2.27 445 44.7 22 41
      QA8AALD115NP48S08W 1/2" 115 200 102 2.61 452 50.0 25 41
      QA8AALD150NP48S08W 1/2" 150 145 133 2.94 489 50.0 25 41
      QA8AALD200NF56S12W 3/4" 200 110 178 3.84 508 53.2 30 41
      QA8AALD225NF56S12W 3/4" 225 90 222 3.84 508 53.2 30 41

  •
    • Air Angle Grinders

    • We Offer Number of Models in Air Angle Grinders  that are listed as below:

      1) G3A120PP95AV *****

      Features:

      »  Advanced Industrial 125 mm wheel grinder.

      »  High torque 1 kW motor.

      »  2000 hour life angle head.

      »  Autobalancer and anti-vibration handle as standard.

      »  Piped away exhaust.

      »  Also available without anti-vibration handle, model no. G3A120PP95A.

      2) G2A120PP95 *****

      Features:

      »  Advanced Industrial 125 mm wheel grinder.

      »  0.6 kW motor.

      »  2000 hour life angle head.

      »  Piped away exhaust.

      »  One nut removal for motor repairs.

      3) 320AG3 ****

      Features:

      »  Weld cleaning and finishing with 3" wheel.

      »  Internal wick lubricator extends angle gear life.

      »  Optional piped away exhaust available.

      4) 3102 ***

      Features:

      »  Mini angle grinder with multipositional head.

      »  Positive grip 6 mm capacity collet chuck.

      »  Ergonomic and durable composite housing.

      »  Lightweight durable design.

      5) LA421-EU ** / LA422-EU **

      Features:

      »  All purpose angle grinders suitable for metal dressing, rust removal, weld preparation and automotive body work.

      »  Wheel capacity 100 mm (LA421-EU) & 125 mm (LA422-EU).

      Technical Specifications:

  •
    • Air Pistol Grip & Straight Drills

    • We Offer Number of Models in Air Pistol Grip & Straight Drills that are listed as below:

      1) 1AL1 *****

      Features:

      »  Precise maintenance and heavy duty work.

      »  Only 159 mm length: provides convenient access for tight spaces.

      »  Precision control through variable trigger.

      »  Soft touch coating for secured grip with minimal grip force.

      2) 5ALST4-EU *****

      Features:

      »  Precise maintenance and heavy duty work.

      »  Compact and lightweight design.

      »  Precision control through variable trigger.

      »  Soft touch Skinsulate coating for secured grip with minimal grip force.

      3) 6AMST6-EU *****

      Features:

      »  For general maintenance and heavy duty work.

      »  Compact and lightweight design with 10 mm chuck capacity.

      »  Precision control through variable trigger.

      »  Soft touch Skinsulate coating.

      4) 7ANST8-EU *****

      Features:

      »  For general maintenance and heavy duty work.

      »  High capacity chuck.

      »  Soft touch Skinsulate coating.

      »  Precision control through variable trigger.

      »  Dead handle included.

      5) 1LL1 *****

      Features:

      »  Very compact and versatile drill with only 17 mm side to centre distance.

      »  Weights only 0.5 kg.

      »  6 mm chuck capacity.

      »  Precise speed control by lever.

      »  Soft touch coating for secured grip with minimal grip force

      Technical Specifications:

  •
    • Air Random Orbital Sanders

    • We Offer Number of Models in Air Random Orbital Sanders that are listed as below:

      1) RO26B-CLV-1 *****

      Features:

      »  Fine sanding and finishing of wood & composites.

      »  One piece composite housing.

      »  Supplied vacuum ready.

      »  Twin roller bearing assemblies with fully machined counterbalance assemblies.

      2) 4151-HL **** / 4151-HL-2 ****

      Features:

      »  5 mm orbit random orbital sanders for body shops applications and surface preparation.

      »  Ergonomic and lightweight design.

      »  Advanced composite rotor and vanes – non lube, oil free operation.

      »  Vacuum ready.

      »  Model with long handle, no. 4151-HL-2.

      3) 4152-HL-SR ****

      Features:

      »  Indispensable tool for small alterations and spot repairs.

      »  High finishing with 2.5 mm orbit and 75 mm sanding pad.

      »  Ergonomic, lightweight and vacuum ready.

      »  Advanced composite rotor and vanes – non-lube, oil free operation.

      4) 311A **

      Features:

      »  Feather edging, metal preparation and body filler finishing work.

      »  Orbital for swirl-free, quality finishing prior to painting.

      »  Adjustable built-in regulator – Built in silencer.

      REPLACEMENT PADS FOR RANDOM ORBITAL SANDERS

      • 75 mm (3") diameter - Velcro* : part no. 010056

      • 150 mm (6") diameter - Velcro* : part no. 49835

      • 150 mm (6") diameter - Vinyl : part no. 49099-1

      * Velcro pads can be used for both vacuum and non-vacuum models.

      Technical Specifications:

  •
    • Grease Pump (Pro-Series Pumps)

    • Specialty Pumps - Grease Packages

      Grease Package Performance Specifications:

      Ratio: 50::1
      Maximum Delivery/Min.: 7.5-lbs. (3.4-kg)
      Maximum Rec’d Cycles: 135 per minute (LM2350E-X1-B)
      Displacement per Cycle: 0.875-In3 (14.33-cm3)
      Air Inlet: (Female) 1/4 - 18 N.P.T.F. - 1
      Material Inlet: Immersed
      Material Outlet: 3/8 -18 N.P.T.F. - 1
      Max. operating pressure: 150-psi (10.3-bar)
      Max. fluid pressure: 7500-psi (517.2-bar)
      Weight: lbs (kg) 42.1 (19.1)



      LP3003-1 Major Components:

      Item: Description:
      Basic 50:1 Grease Pump: LM2350E-31-B
      Drum Cover: 94421
      Follower Plate: 640165
      Material Hose: 624201-10
      Booster Grease Gun: 636103
      Z-Swivel: 636077
      Dolly Assembly: 640057



      Accessories:

      Air Line Connection Kit* | Kit No. 66073-1

      Kit includes Piggyback Filter/Regulator with gauge, pipe nipple and a 5-foot section of air hose.

      Service Repair Kits | Kit No. 637227-B

      (Pump Rebuild Kit: Contains necessary soft parts to rebuild entire pump.)

      *Please note pumps are not included with these kits.

First Prev Page 1 / 6 (52 records) |  Next Last
Go to
